To transport and transfer blood, plasma, vaccine, reagents and special medicines in medical and logistics industry.
Features
l Multiple voltage used as AC 220V or DC 12V/24V (power supply of cigarette lighter)
l Microprocessor control, digital display, and temperature adjustment with an increment of 0.1℃
Large digital display screen
l Muti function: 2 ranges of inner temperature to choose and set:
2~8℃ used as pharmacy refrigerator
-10~-25℃ used as deep freezer
l Permanently lubricated cooling fan for safety and longevity
l High efficiency specialty compressor with known field reliability
l Forced- air cooling with optimized air distribution system designed
Safety
l Build-in back-up battery to display temperature and to operate audible and visual alarm system for up to 8 hours without AC power.
l Visual and audible alarm system: High/low temperature, thermostat failure alarm, power failure alarm
l Power failure protection: turn on delay of the cooling system when power failure, restart delay protection.
l Keyboard lock, password protection to avoid set parameter randomly.
l PE structure for whole unit to prevent cabinet broken from drop or fail down.
Certificate:
l CE;ISO14001.ISO9001.ISO13485.ISO45001
Warranty：
l 1 year free spare parts and remote technical support.
Performance | Refrigeration System | ||||
Temperature Range | +2~+8℃/-10~-25℃ | Compressor | 1 | ||
Ambient Temperature | 10~32°C | Refrigerant | R134a | ||
Controller | Microprocessor | Cooling Type | Direct cooling +Forced-air cooling | ||
Display | Digital Display | Defrost Type | Manual defrost | ||
Electrical Data | Alarm | ||||
Power Supply(V/Hz) | 220/50~60; AC12V/24V | High/Low Temperature | Y | ||
Rated Power(W) | 80W | Power Failure | Y | ||
Electrical Current(A) | DC 6.5A | Sensor error | Y | ||
Power Consumption | 1.2kWh/24h | Thermostat failure | Y | ||
Dimensions | Accessories | ||||
Capacity | 30L | Back up battery for power failure alarm | 8 hours | ||
Interior Size(W*D*H) | 364*253*352.5mm | Lamp | LED | ||
Exterior Size(W*D*H) | 610*360*460mm | Door | 1/Solid door | ||
Package Size(W*D*H) | 680*445*535mm | Noise (db) | 45 | ||
N.t./G.t. (approx) | 23.5/26.5kg | Shelves | Basket around Evaporator | ||
Loading Qty (20'/40'/40H) | 160/340/425 | Temperature recorder | Optional | ||
