Lubricating Grease Dropping Point Tester

Model ID: DP22017

Overview
Lubricating grease dropping point tester conforms to the ASTM D566 Standard Test Method for Dropping Point of Lubricating Grease, the apparatus determinates the dropping point of lubricating grease, which is not recommended for use at bath temperatures above 288°C. For higher temperature’s test.
Our HK- 2019 (ASTM D 2265) should be used.

Features

1. Output adopts solid state relay without contact, sparkle, noise and it has long operating life.
2.
It can test two kinds of sample oil at the same time through the tube bracket.
3.
Reasonable structure with beautiful shape and environment friendly.



Technical parameters

1.Power voltage:AC220V±10%  50Hz

2.Power:0800W, continuously adjustable

3.Temperature controller method: solid state voltage regulator stepless voltage regulation.

4.Stirring method: engine stirring 220V, 500 r/min

5.Glass bath:800ml

6.Testing holes: double

7.Lighting: LED light source 220V

8.Ambient requirements: Temperature : 1040  humidity≤85%

9. Net dimension: 250*300*350mm, 5.5kg
